153-0773-3338
※驅動器集成過壓過流保護功能
※輸入信號光隔離
※雙極恒流斬波方式
※直流供電20-50VDC （建議24-45VDC工作）
※最大驅動電流4.2A
※低速零震動，且噪音及小
※高細分:2,4,8,16,32,64,128,5,10,20,25,40
50,100,125
※抗干擾能力強，在電網惡劣的環境里
可以實現高精度定位
※高可靠性：功率器件留有足夠裕量,
出廠經過嚴格測試
| 冷卻方式 | 自然冷卻或強制風冷。 |
| 場合 | 不能放在其他發熱的設備旁，要避免粉塵、油污、腐蝕性氣體、濕度 太大及強震場所，禁止有可燃?xì)怏w和導電灰塵。 |
| 濕度 | 40-90％RH |
| 震動 | 10-55Hz/0.15mm |
| 保存溫度 | -20-65℃ |
| 重量 | 0.25KG |
| 運行電流 | SW1 | SW2 | SW3 |
| 1.00A | ON | ON | ON |
| 1.46A | OFF | ON | ON |
| 1.91A | ON | OFF | ON |
| 2.37A | OFF | OFF | ON |
| 2.84A | ON | ON | OFF |
| 3.31A | OFF | ON | OFF |
| 3.76A | ON | OFF | OFF |
| 4.20A | OFF | OFF | OFF |
| 脈沖/圈 | SW5 | SW6 | SW7 | SW8 |
| 400 | OFF | ON | ON | ON |
| 800 | ON | OFF | ON | ON |
| 1600 | OFF | OFF | ON | ON |
| 3200 | ON | ON | OFF | ON |
| 6400 | OFF | ON | OFF | ON |
| 12800 | ON | OFF | OFF | ON |
| 25600 | OFF | OFF | OFF | ON |
| 1000 | ON | ON | ON | OFF |
| 2000 | OFF | ON | ON | OFF |
| 4000 | ON | OFF | ON | OFF |
| 5000 | OFF | OFF | ON | OFF |
| 8000 | ON | ON | OFF | OFF |
| 10000 | OFF | ON | OFF | OFF |
| 20000 | ON | OFF | OFF | OFF |
| 25000 | OFF | OFF | OFF | OFF |
